Duinotech MEGA 2560 r3 Main Board with Motor Controller Expansion
Code: 8008557
- This powerful Arduino compatible ATMEGA2560 development board has integrated motor driving chips, which makes it a perfect solution for robotics or driving 2 or 4WD car kits. Power from a USB source or a 7-12VDC battery (sold separately).
XC4461
The TB6612 chips and supported electronics provide enough power to independently control four motors up to 12VDC with a driving current of up to 1.2A. The core ATMEGA2560-16AU processor supports 54 digital I/O ports (12 designed for motors) of which 15 can be used as PWM outputs (4 for motors), 16 analog inputs, and 4-channel serial communication ports (port 0 for programming). The board can also output 5V up to 3A across 3 channels to power external sensors or modules. Other features include 16MHz quartz crystal, a USB interface, DC power input, an ICSP plug and a reset button.
Features:
- Arduino MEGA2560 compatible
- Integrated 4-channel motor driver
- Support for 7-12VDC battery
- I2C Interface
- USB Interface
