CP PFC SINEWAVE SERIES 1600VA
Code: 8217744
- The CyberPowerPFC UPS with Pure Sine Wave output is designed to protect mid to high-end computer systems, servers, and networking hardware using both conventional and Active Power Factor Correction (PFC) power supplies. It features GreenPower UPS Technology for improved energy efficiency.
Specifications:
- Form Factor: Tower
- UPS Topology: Line-interactive
- Energy Saving Technology: GreenPower UPS Bypass Technology
- Active PFC Compatibility: Yes
- Nominal Input Voltage (Vac): 220, 230, 240
- Input Voltage Range (Vac): 169 - 271
- Input Frequency (Hz): 50 ± 3, 60 ± 3
- Input Frequency Detection: Auto-sensing
- Rated Input Current (A): 10
- Input Connector Type: IEC C14
- Detachable Power Cord Plug Type: Schuko
- Power Cord Length (m): 1.83
- Capacity (VA): 1600
- Capacity (Watts): 1000
- On Battery Waveform: Pure Sine Wave
- On Battery Voltage(s) (Vac): 230 ± 5% (under test load <60%)
- On Battery Frequency (Hz): 50 ± 1%, 60 ± 1%
- Automatic Voltage Regulation (AVR): Single Boost
- Overload Protection: Internal Current Limiting
- Outlets: 6 Schuko (Battery & Surge Protected)
- Typical Transfer Time (ms): 8 (Max 12ms at normal sensitivity)
- USB Charging Ports: USB-A x 1, USB-C x 1
- USB Charging Total Output (Watts): 30
- USB-A Charging Output: 5 V/2.4 A Max
- USB-C Charging Output: 5 V/2.5 A Max, 9 V/2 A Max, 15 V/2 A Max
- Runtime at Half Load (min): 9.7
- Runtime at Full Load (min): 2.6
- Typical Recharge Time (Hours): 8 (90% recovery after full load discharge)
- User-replaceable: Yes
- Battery Type: Sealed Lead-acid
- Replacement Battery Pack (RBP): RBP0142
- Replacement Battery Pack Quantity (pcs): 1
- Surge Suppression (Joules): 405
- Network Protection RJ45: 1-in, 1-out
- LCD Panel: Color LCD, Tiltable 22°
- LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Event & Log
- LCD Setting & Control: Alarm Setting, Input & Output, Battery Setting, Event & Log
- LED Indicators: Power On
- HID-Compliant USB Port(s): 1
- Serial Port: Dry Contact
- Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
- Management Cable (pcs): USB Cable x1
- Ethernet Data Transmission Speed: Up to 1Gbps
- Power Management Software: PowerPanel Business (Recommended)
- SNMP/HTTP Remote Monitoring: Yes, with optional RMCARD205
- Dimensions: 100 x 280 x 355mm
- Weight: 11kg
- Operating Temperature: 0 - 40°C
- Operating Relative Humidity (Non-condensing): 0 - 95%
- Operating Elevation: 0-3,000m
- Storage Temperature: -15 - 45°C
- Storage Relative Humidity (Non-condensing): 0 - 95%
- Storage Elevation: 0-15,000m
- Online Thermal Dissipation (BTU/hr): 24
- Certifications: CE, RoHS
- Warranty: 2-year
Features:
- Line-interactive UPS Topology
- Active PFC Compatibility
- Automatic Voltage Regulation (AVR)
- LED Status Indicator
- PowerPanel Management Software
- USB Charging Ports
- Tower Form Factor
- Energy Saving Technology
- Pure Sine Wave Output
- Color LCD Panel
- SNMP/HTTP Remote Management Capability (Optional)
- Surge and Spike Protection
- High-speed Ethernet Data Transmission
