LED backlighting, low power consumption and reduced heat output. 701755
The Elo 3243L 32-inch full HD open-frame touchscreen delivers a professional-grade large-format display and sleek design at less than 2.3 inches (58 mm) in total thickness. Designed for touch from the start with proven Elo expertise and reliability built in, the 3243L offers a state-of-the-art slim design using LED backlighting, reducing power consumption and heat to enable thinner and smaller kiosk designs for various applications in retail, hotels, gaming, transportation and other commercial uses. The touchscreen glass is tested with robust UL60950 ball-drop requirements, supporting applications in demanding public access environments. The comprehensive range of features includes analog and digital interfaces, multi-lingual and cabled remote on-screen display (OSD), mounting VESA standard, mounting brackets, and worldwide compliance.
Our TouchPro PCAP technology supports touch through functionality for installations that require a front layer of glass with thickness s up to 6mm or solutions that require specific IP ratings. Whether you need a flush-mounted display or one that is fully-encased behind a cover glass, our robust PCAP Open Frames are purpose-built for durability in various applications and environments: from self-service kiosks to highly used gaming cabinets to harsh industrial machines.
Specifications
Touch Technology & Capacity: PCAP (TouchPro Projected Capacitive) - 10 Touch
Diagonal Size: 31.5" diagonal, Active matrix TFT LCD (LED)
Aspect Ratio: 16:9
Active Area: 700.4 x 394.9mm
Resolution: 1920 x 1080
Horizontal Viewing Angle: 89 or 178 total
Vertical Viewing Angle: 89 or 178 total
Number of Colors: 16.7 million
Brightness (typical) LCD panel: 500 nits
Brightness (typical) PCAP: 425 nits
Response Time-total: 8 msec
Contrast Ratio: 3000:1
Input Video Format: HDMI, VGA
Touch Interface: USB
Power Supply: Internal AC
Input Voltage: AC 100-240VAC, 50/60Hz,
Input Connector: IEC 60320 C14
Power Consumption (Monitor + PSU) ON: 47.9W
Power Consumption (Monitor + PSU) SLEEP: 0.9W
Power Consumption (Monitor + PSU) OFF: 0.1W
Operating Temperature : 0 C to 40 C
Humidity Operating: 20% to 80%
Sealability : Touchscreen sealed to bezel; Touchscreen sealed to LCD
Enclosure Colour: Black
Monitor Dimensions: 747.3(W) x 452.7(H) x 55(D)mm
Weight: 11.2 kg
