Lindy USB-C Docking Station
Code: DYNSUP/LIN43349
- Feature packed docking station designed to deliver unrivalled video output. Housed in an aluminium body, this dock delivers great additional connectivity for your device. A space-saving stand is also included to help keep your workspace clutter-free.
Specifications:
- Interface: USB Type C to 3 x USB Type A / 1x USB Type C / 1x RJ45 / 2x DisplayPort / 1x HDMI / 1x SD & 1x MicroSD / 1x 3.5mm audio
- Interface Standard: USB 3.2 / 3.1 Gen 1 / USB 3.0
- Gigabit LAN
- DP 1.4
- HDMI 2.0
- SD/TF 3.0
- 3.5mm Audio (combo)
- Supported Bandwidth: 5 Gbps
- 10/100/1000 Mbps
- Maximum Input Resolution: 7680x4320@60Hz
- Maximum Output Resolution: Single Display: 5120x2880 60Hz (DP) & 3840x2160 60Hz (HDMI)
- Dual Displays: 5120x2880 60Hz (DP) & 3840x2160 30Hz (HDMI)
- Triple Displays: 3480x2160 30Hz (HDMI) & 3480x2160 60Hz (DP) & 2560 x1440 60Hz (DP) or 3480x2160 30Hz (HDMI) & 4K 60Hz (DP) & 4K 30Hz (DP)
- Chipset: VL103R
- VL170
- VL817
- VL815
- VMM5320
- RTL8153B
- GL3224
- HS-100B
- T25S40
- GD25Q40
- Compatibility: USB Type C or Thunderbolt 3 equipped computers with DisplayPort Alternate Mode support
- Power Delivery: PD 3.0 up to 100W (20V 5A)
- HDCP Support: HDCP 2.2
- Supported Audio: Supports Audio 7.1 Channel
- Separate Audio Ports: 1 x Audio combo port 3.5mm
- Special Features: DisplayPort Alternate Mode
- 1x Battery Charging 1.2 port
- Supports MST for Windows
- PXE (Preboot Execution Environment) and Wake on LAN (WOL) support
- Inputs: 1 x USB Type C (Female)
- Outputs: 3 x USB Type A (Female)
- 1 x USB Type C (Female)
- 1 x RJ45 (Female)
- 2 x DisplayPort (Female)
- 1 x HDMI (Female)
- 1 x SD (Female)
- 1 x MicroSD (Female)
- 1x 3.5mm audio jack
- Power Supply: 5.5/2.5mm DC socket
- 1 x USB Type C (Female) PD port
- Dimensions WxDxH: 180 x 77 x 18mm
- Housing Material: Aluminium
- Net Weight: 0.439kg
- Power Requirements: 24W
- Packaging Dimensions: 200 x 120 x 70mm
- Gross Weight: 0.78kg
- Warranty (Years): 2
- Certificated: CE
- FCC
- REACH & RoHS
- California Proposition 65
Features:
- Connects an HDMI and/or up to 2 DisplayPort displays, USB peripherals and power over a single cable
- Supports 5K 60Hz for a single DisplayPort display or 4K 60Hz for a single HDMI display
- Integrated 4 port USB SuperSpeed 5Gbps Hub (3 x Type A
- 1 x Type C)
- USB Power Delivery capable up to 100W
- Extend your Displays
- Added Connectivity
- Plug-and-Play
- 2 year warranty
