Specifications:

• Interface: USB Type C to 2x HDMI / 2x USB Type A / 1x USB Type C / 1x RJ45 / 1x Audio 3.5mm
• Interface Standard: USB 3.2 / 3.1 Gen 1 / USB 3.0
• HDMI 1.4 + 2.0
• Gigabit LAN
• Audio (combo)
• Supported Bandwidth: 10.8Gbps (HDMI 1.4)
• 18Gbps (HDMI 2.0)
• 5Gbps (USB 3.0)
• 10/100/100Mbps (LAN)
• Maximum Input Resolution: 3840x2160@60Hz
• Maximum Output Resolution: Single display: 4K 60Hz
• Dual display: 1x 4K60Hz
• 1x 4K30Hz
• Chipset: SM768
• ANX7518
• 2xVL817
• AX88179A
• HS-100B
• IM2600
• Compatibility: USB Type C or Thunderbolt 3 equipped computers
• Power Delivery: PD 3.0 up to 100W (20V 5A)
• HDCP Support: HDCP 2.2
• Supported Audio: Supports 48/44.1kHz Audio sampling rate
• Separate Audio Ports: 1x Audio combo port 3.5mm
• Special Features: USB Type C Female port supports power and data
• 2x Battery Charging 1.2 port
• Software-based Silicon solution to connect any display to any computer that supports USB
• compatible with Windows and MacOS; MST dual display for Apple M1
• Inputs: 1 x USB Type C (Male)
• Outputs: 2x HDMI (Female)
• 1x RJ45 (Female)
• 2x USB Type A (Female)
• 1x USB Type C (Female) / 1x 3.5mm Audio (Female)
• Power: 1 x USB Type C (Female) PD port
• Dimensions WxDxH: 140 x 65 x 20mm
• Housing Material: Aluminium
• ABS (RJ45 port cover)
• Net Weight: 0.2kg
• Power Requirements: Bus-powered
• Packaging Dimensions: 207 x 137 x 38mm
• Gross Weight: 0.3kg
• Warranty (Years): 2
• Certificated: CE
• UKCA
• FCC
• REACH & RoHS
• California Proposition 65

Features:

• Adds Dual 4K 3840x2160 HDMI displays to Windows and Apple M1 PC's
• Provides 2 USB Type A ports & 1 USB Type C port (5Gbps) Gigabit Ethernet and an Audio combo port
• Software-based Silicon solution to connect any display to any computer that supports USB
• USB Power Delivery 3.0 (100W) allows charging the laptop while using the DST-Mx Duo
• Extend your Displays
• Added Connectivity
• Easy Driver Installation
• 2-year warranty

Downloads:

• LIN43360.pdf
