Mean Well 100W Rail Mount Switchmode PSU 13.8VDC 2.8A

Code: 8072112
Stock Status:
Delivery (2-5 Days)
  • Dual output DIN rail power supply by Mean Well.

    MP3903

    In addition to the primary output, there is a charger output with a smaller rated current, enabling backup power supply applications for security access systems. With a rated efficiency of 86%, it can operate with air convection cooling in temperatures from -30 to 70 degress Celsius . Key protection features include over-temperature, over-voltage, battery low cut off, and battery reverse polarity protection (by fuse).

    Specifications:
    Output Voltage: 13.8VDC
    Current: 2.8A/1.5A
    Power: 59.34W
    Ripple Voltage: 120mV p-p
    Input Voltage: 90-264VAC
    Input Frequency: 47-63Hz
    Inrush Current: 30A@115VAC, 60A@230VAC

$74.41

EACH

Add

Please note: Prices are shown including GST (where applicable) and are in AUD$
