Shielded 3 Inch 15W 8-Ohm Full Range Speaker

Code: 8066548
Stock Status:
Delivery (2-5 Days)
  • An 8 ohm 15W speaker suitable for use in many projects.

    AS3034

    1 Year Warranty

    Full range speakers suitable for use in surround speakers in home theatre system, computer multimedia speakers and portable speaker designs. It has advanced alloy cone design coated with special damping material.

    4 x screw mounting holes

    General Data
    Max Power Handling (Pmax)(W): 30
    Weight (M)(Kg): 0.53

    Electrical Data
    Nominal Impedance (Z)( )): 8
    DC (Re)( ): 6.5

    Voice Coil and Magnet Parameters
    VC Diameter (mm): 20
    VC Length (H)(mm): 9
    VC Former: Kapton
    VC Frame: CCAW
    Magnet System: shielded
    Magnet Former: Ferrite
    Force Factor (BL)(N/A): 3.06
    Gap Height (He)(mm): 3
    Linear Excursion (Xmax)(mm): 3

    T-S Parameters
    Suspension Compliance (Cms)(uM/N): 920
    Mechanical Q (Qms): 3.75
    Electrical Q (Qes): 1.15
    Total Q (Qts): 0.88
    Moving Mass (Mms)(g): 2.6
    Effective Piston Area (Sd)(m2): 0.003
    Equivalent Air Volume (Vas)(L): 1.19
    Resonance Frequency (Fs)(Hz): 100

$23.27

EACH

Add

Please note: Prices are shown including GST (where applicable) and are in AUD$
